Model UN-600S cementing truck is designed for injection of various fluids while cementing, for development and workover of wells and for other preflush and overflush operations.
Specifications
|
Model |
Measurement |
UN-600S |
||||
| Caterpillar, Weichai engine | unit | 1 | ||||
| Allision 4700OFS automatic transmission | unit | 1 | ||||
| Fluid mechanics | – | from chassis engine | ||||
| Triplex plunger pump DTP 600S HD (600 l.s.) | unit | 1 | ||||
| Mixer | – | Off center | ||||
| Cement flow control valve | – | Off center | ||||
| Water supply centrifugal pump 4×3 | unit | 1 | ||||
| Booster centrifugal pump RA56 | unit | 1 | ||||
| Densiometer | – | Micro Motion 3” F3000 | ||||
| Main controller | – | Allen-Bredley PLC | ||||
| Mixing tank | m3 (bar) | 1.4 (8) | ||||
| Cement surge tank | m3 (bar) | 2х1.5 (20) | ||||
| Gauge tank | m3 (bar) | 2х1.5 (2х10) | ||||
| Fuel tank | l. | 400+300 l. | ||||
| Hydraulic tank | l. | 170 | ||||
| Air receiver | l. | 80 | ||||
| Hydro block | – | 3” | 3 1/2” | 4” | 4 1/2” | |
| Pressure | PSI (MPa) | 14000 (97.5) | 10000 (69) | 8000 (56) | 6000 (43) | |
| Capacity | m3/min | 0.95 | 1.27 | 1.67 | 2.13 | |
